CUSTOM CABLE WORKSPACE 01 / SPECIFY

Build the cable
you actually need.

Define an FT232RL-based assembly, map every wire, and check the manufacturing drawing before ordering samples.

2-week buildThen domestic ground transit
Manufacturing drawingLIVE PREVIEW · MM
PT–FTDI / REV A
1.Cable Length: 1800±20 P1 FTDI FT232RL 1 4 3 2.Pin Connect: P1 USB P2 RJ11 3.Packaging: 180±5 130±5 5 6 1 2 3 4 5 6 NO. FT232RL+SP485 PCBA Semi-product USB A Type Male, Solder Type, Gold Flash , Color White RJ11 6P4C 26AWG(7/0.16TC)*3C OD=5.0 Jacket Color Black L=1800MM 45P Transparent PVC Mini Tie, Color: Black, L=80mm ESD Bag W:130MM L:180MM T:0.05MM Name of Material 1SET 1PCS 1PCS 18g 1PCS 1PCS Usage ITEM: USB-RS485-RJ11 Approval Check Drawer Unit Date Horizon Version MM A.0
Drawing updates as you define cable details.Exports: PDF · SVG · PNG
